High Speed Vacuum Compression Molding Machine Energy Saving

Name: High Speed Vacuum Compression Molding Machine Energy Saving
Brand: Fulund
Price: 1 USD

China High Speed Vacuum Compression Molding Machine Energy Saving wholesale

Brand Name : Fulund

Model Number : FLD-B09-1

Certification : CE

Place of Origin : CHINA

MOQ : 1

Price : competitive

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 100PCS/MONTH

Delivery Time : 7days

Packaging Details : WOODEN CASE

NAME : Flat vulcanizing machine

Automatic grade : Semi-Automatic, Automatic, manual

Core Components : PLC

Dimension(L*W*H) : 1400*2000*1600MM

Voltage : AC380V±5%

Power (kW) : 12

Keyword 1 : compression molding machine price

Keyword 2 : Vacuum Compression Molding Machine

Keyword 3 : Molding Machine

Contact Now

High Speed Energy-Saving Vacuum Compression Molding Machine Price

Fulund has a long history since its establishment in 1999. Due to the needs of development, the original brand (TYL) expanded the new brand Fulund in 2022 . Fulund has customers all over the world,such as international brands shoe manufacturer.

Automatic Vacuum Compression Molding Machine is suitable for vulcanization molding of Natural Rubber, Acrylonitrile Rubber, EPDM Rubber, Chloroprene Rubber and Silicone, and some rubber products produced by vulcanization molding, such as frame oil seal, seal ring, organ sets ect. It is also be used to the forming and shallow tensile technique of bakelite thermosetting materials,magnetic material and powder metallurgy products.

This vacuum compression molding machine collects vacuum and vulcanization molding technology in one machine. It is not only high automatically and efficient, but also improves quality of the products efficiently. It is your ideal one for the rubber material products.

Model	30T	40T	50(63)T
Temperature regulation	At room temperature ~ 300	At room temperature ~ 300	At room temperature ~ 300
normal temperature-200 degrees heating speed	about15min	about15min	about15min
Temperature precision	automatic/±2°C	automatic/±2°C	automatic/±2°C
Machine operation	control Circuit	control Circuit	PLC touch-screen
Drive way	hydraulic	hydraulic	hydraulic
pressure	10-20Mpa	10-20Mpa	10-20Mpa
power supply	AC380V ± 5%50/60Hz	AC380V ± 5%50/60Hz	AC380V ± 5%50/60Hz
Power:	12KW	15KW	18KW
Motor Power	4KW	4KW	5.5KW
Heating plate distance	200MM	200MM	200MM
Oil cylinder stroke	200MM	200MM	200MM
Movement mode of skateboard	Automatic	Automatic	Automatic
Speed of rise and fall	≥15mm/s	≥15mm/s	≥25mm/s
Pressure regulation mode	Pressure relay	Pressure relay	Digital modulation
Hot pressing time	0.1s to 999s	0.1s to 999s	0.1s to 999s
Maximum pressure	300KN	400KN	500(630)KN
Sliding plate area	440 * 500MM	440 * 500MM	460 * 550MM
Heating plate area	400 × 400MM	400 * 400MM	400 * 450MM
host volume	1400 × 2000 × 1600MM	1400 × 2000 × 1700MM	1500 × 2000 × 1800MM
weight	1200KG	1350KG	1500KG
